Technical details

Model

JDZDJ40-630

Paper Roll Width

180-550mm

Tube Length

150-630mm

Bag Body With

50-170mm

Bottom Size

35-100mm

Paper Thickness

60-100g/m²

Max. Paper Roll Diameter

φ1200mm

Material Core Diameter

φ76mm

Max. Production Speed

180-160bags/min

Total Power

380V 50Hz 4.5kw/12.5KW

Weight of Machine

approx.3000kg

Overall Dimension(L*W*H)

L6000mm*W1200mm*H1700mm
