Model | PFK 2508 | PFK 2516 | |
Ink sprayer | Micro piezoelectric high-precision nozzle | ||
Sprayer quantity | 8 pcs | 16 pcs | |
Ink type | Water-based dye ink for cardboard | ||
Colors | C/M/Y/K | ||
Spraying height | 2-4mm | ||
Printing precision | More than 360*600 dpi | ||
Printing speed | 600 square meters/hour | 1200 square meters/hour | |
Printing max area | 2500*1350mm | ||
Drying speed | Immediately after printing | ||
Working temperature | Workshop temperature 20-25 degree, 50%-70% humidity | ||
Ink supply | Automatic continuous ink supply | ||
Cardboard feeding | Front lead edge automatic feeding | ||
Max feeding pile height | 43 cm | ||
Cardboard thickness | 3-30mm | ||
Software | Professional RIP software | ||
Operation System | WIN7/WIN10 | ||
Working power | 380V 50-60Hz 3Phases, about 20KW | ||
Machine sizes(L*W*H) | 5645*3750*2123mm | 5645*4150*2123mm | |
Machine Weight (KG) | About 4500KGS | About 5000KGS | |
