Technical details

Electric separate

Yes

Equipped with blower

Yes

Front edge suction auto feeding

Yes

Max feeding cardboard

1400*600mm (other sizes can be customized)

Min feeding cardboard

430*170mm

Positive slotting sizes

150*50 mm

Negative slotting sizes

80*80 mm

Cardboard thickness

2--8 mm

Box min height

70mm

Design working speed

150 sheets/min

Printing roller diameter

210+-1mm

Working speed

80-120 sheets/min

Working power

380V/50Hz/3Phase 13KW (includes blower)

Precision

±0.5 mm

Machine sizes (L*W*H)

                            About  3200*2300*1600 mm

Weight

About 3600 KGS
